P-793H User’s Guide
Chapter 23 WAN Setup 255
C
H A P T E R
23
WAN Setup
Use this menu to configure the DSL connection, traffic redirect, and dial-backup interface.
23.1 WAN Setup
From the main menu, enter 2 to open menu 2.
Figure 138 Menu 2: WAN Setup
The following table describes the fields in this screen.
Menu 2 - WAN Setup
Service Mode= 2wire
Service Type= Server
Rate Adaption= Enable
Transfer Max Rate(Kbps)= 192
Transfer Min Rate(Kbps)= 192
Standard Mode= ANSI(ANNEX_A)
Wan Backup Setup:
Check Mechanism = DSL Link
Check WAN IP Address1 = 0.0.0.0
Check WAN IP Address2 = 0.0.0.0
Check WAN IP Address3 = 0.0.0.0
KeepAlive Fail Tolerance = 0
Recovery Interval(sec) = 0
ICMP Timeout(sec) = 0
Traffic Redirect = No
Dial Backup = No
Table 93 Menu 2: WAN Setup
FIELD DESCRIPTION
Service Mode Press [SPACE BAR] to indicate whether the ZyXEL Device should use 2-wire or 4-
wire mode for the DSL connection. This is related to the phone line you use and
affects the maximum speed of the connection. In 2-wire mode, the maximum data
rate is up to 5.69 Mbps, while in 4-wire mode, the maximum data rate us up to 11.38
Mbps.
Service Type Press [SPACE BAR] to indicate whether the ZyXEL Device is the server or the client
in the DSL connection. Select Server if this ZyXEL Device is the server in a point-to-
point application. (See Chapter 4 on page 67 .) Otherwise, select Client.
Rate Adaption This field is enabled if Service Type is Server. Press [SPACE BAR] to let the ZyXEL
Device adjust the speed of its connection to that of the other device.
