P-793H User’s Guide
308 Chapter 30 Filter Configuration
For generic rules, the ZyXEL Device treats a packet as a byte stream as opposed to an IP or
IPX packet. You specify the portion of the packet to check with the Offset (from 0) and the
Length fields, both in bytes. The ZyXEL Device applies the Mask (bit-wise ANDing) to the
data portion before comparing the result against the Value to determine a match. The Mask
and Value are specified in hexadecimal numbers. Note that it takes two hexadecimal digits to
represent a byte, so if the length is 4, the value in either field will take 8 digits, for example,
FFFFFFFF.
To configure a generic rule, select Generic Filter Rule in the Filter Type field in menu
21.1.1.1 and press [ENTER] to open Generic Filter Rule, as shown below.
Figure 188 Menu 21.1.1.1: Generic Filter Rule
The following table describes the fields in the Generic Filter Rule menu.
Menu 21.1.1.1 - Generic Filter Rule
Filter #: 1,1
Filter Type= Generic Filter Rule
Active= No
Offset= 0
Length= 0
Mask= N/A
Value= N/A
More= No Log= None
Action Matched= Check Next Rule
Action Not Matched= Check Next Rule
Table 115 Menu 21.1.1.1: Generic Filter Rule
FIELD DESCRIPTION
Filter # This is the filter set, filter rule co-ordinates, i.e., 2,3 refers to the second filter set and the
third rule of that set.
Filter Type Use [SPACE BAR] and then [ENTER] to select a rule type. Parameters displayed below
each type will be different. TCP/IP filter rules are used to filter IP packets while generic
filter rules allow filtering of non-IP packets.
Options are Generic Filter Rule and TCP/IP Filter Rule.
Active Select Yes to turn on the filter rule or No to turn it off.
Offset Enter the starting byte of the data portion in the packet that you wish to compare. The
range for this field is from 0 to 255.
Length Enter the byte count of the data portion in the packet that you wish to compare. The range
for this field is 0 to 8.
Mask Enter the mask (in Hexadecimal notation) to apply to the data portion before comparison.
Value Enter the value (in Hexadecimal notation) to compare with the data portion.
More If Yes, a matching packet is passed to the next filter rule before an action is taken; else the
packet is disposed of according to the action fields.
If More is Yes, then Action Matched and Action Not Matched will be No.
