P-793H User’s Guide
Chapter 26 Remote Node Setup
271
The following explains how to configure remote node 8 for the dial backup connection.
Bridge
If Route is IP, select Yes in this field to enable bridging to this remote node for
protocols that are not supported by IP-based routing (for example, SNA).
If Route is None, select Yes in this field to enable bridging to this remote node
for all protocols.
In either case, this setting is not effective unless you enable bridging in the
ZyXEL Device too. See
.
You should enable either Route or Bridge in this screen, but you should not
enable both of them or disable both of them at the same time.
Edit IP/Bridge
This field is enabled if Route is IP. If you want to set up the WAN IP address
and advanced features for the WAN port, press [SPACE BAR] to select Yes
and press [ENTER]. Menu 11.3 appears.
Edit ATM Options
This field is enabled if Route is IP. Press [SPACE BAR] to select Yes and
press [ENTER] to edit the virtual channel and ATM QoS settings. Menu 11.6
appears.
Edit Advance Options This field is displayed if you are editing remote node 1, and it is only enabled for
PPPoE connections. If you want to set up advanced features for the Internet
connection, press [SPACE BAR] to select Yes and press [ENTER]. Menu 11.8
appears.
Telco Option
This section is only enabled for PPPoA or PPPoE connections.
Allocated Budget(min) Enter the maximum amount of time (in minutes) each call can last. Enter 0 if
there is no limit. With Period, you can set a limit on the total outgoing call time
of the ZyXEL Device within a certain period of time. When the total outgoing
call time exceeds the limit, the current call will be dropped and any future
outgoing calls will be blocked.
Period(hr)
Enter how often (in hours) the Allocated Budget is reset. For example, if you
can call for thirty minutes every hour, set the Allocated Budget to 30, and set
this field to 1.
Schedule Sets
Enter the schedule sets that apply to this connection.
Nailed-Up Connection Select this if you want the ZyXEL Device to automatically connect to your ISP
when it is turned on and to remain connected all the time. This is not
recommended if you pay for your Internet connected based on the amount of
time you are connected.
Session Options
Edit Filter Sets
If you want to specify input and output filter sets for the WAN port, press
[SPACE BAR] to select Yes and press [ENTER]. Menu 11.5 appears.
Idle Timeout(sec)
Enter the number of seconds the ZyXEL Device should wait while there is no
Internet traffic before it automatically disconnects from the ISP. Enter a time
interval between 10 and 9999 seconds.
Table 100 Menu 11.1: Remote Node Profile (nodes 1-7) (continued)
FIELD
DESCRIPTION
