S3F401F_UM_REV1.00 ENCODER COUNTER
4-11
16 Bit Phase A Capture Counter Register PACNT (0x01C) Access: Read/Write
31 30 29 28 27 26 25 24
− − − − − − − −
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
23 22 21 20 19 18 17 16
− − − − − − − −
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
15 14 13 12 11 10 9 8
PACV [15:8]
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
7 6 5 4 3 2 1 0
PACV [7:0]
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
W: Write R: Read -0: 0 After reset -1: 1 After reset -U: Undefined after reset
The Phase A Capture Counter Value Field PACV
0x0000 ~ 0xFFFF
16 Bit Phase A Capture Data Register PACAP (0x020) Access: Read/Write
31 30 29 28 27 26 25 24
− − − − − − − −
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
23 22 21 20 19 18 17 16
− − − − − − − −
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
15 14 13 12 11 10 9 8
PACAPDAT [15:8]
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
7 6 5 4 3 2 1 0
PACAPDAT [7:0]
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
W: Write R: Read -0: 0 After reset -1: 1 After reset -U: Undefined after reset
The Phase A Captured Value Field PACAPDAT
0x0000 ~ 0xFFFF
