INTERRUPT CONTROLLER S3F401F_UM_REV1.00
7-8
3. REGISTERS DESCRIPTION
Table 7-2. Interrupt Controller Special Function Registers
Offset Address Register Description R/W Reset Value
0x000 INTMOD0 Interrupt mode register 0 R/W 0x0000_0000
0x004 INTMOD1 Interrupt mode register 1 R/W 0x0000_0000
0x008 INTMOD2 Interrupt mode register 2 R/W 0x0000_0000
0x00C INTPND0 Interrupt pending register 0 R/W 0x0000_0000
0x010 INTPND1 Interrupt pending register 1 R/W 0x0000_0000
0x014 INTPND2 Interrupt pending register 2 R/W 0x0000_0000
0x018 INTMSK0 Interrupt mask register 0 R/W 0x0000_0000
0x01C INTMSK1 Interrupt mask register 1 R/W 0x0000_0000
0x020 INTMSK2 Interrupt mask register 2 R/W 0x0000_0000
0x024 INTOFFSIRQ Interrupt offset register for IRQ. R 0x0000_007F
0x028 INTOFFSFIQ Interrupt offset register for FIQ. R 0x0000_007F
0x02C INTIRQADDR Interrupt pointer register for IRQ. R 0x0000_0000
0x030 INTFIQADDR Interrupt pointer register for FIQ. R 0x0000_0000
0x034 INTVECBASE Vector Interrupt base address setting register R/W 0x0000_0080
0x038 INTCON Interrupt control register. R/W 0x0000_0000
0x03C INTPRI Interrupt priority register R/W 0x0000_0000
0x040 SWINT Software Interrupt register R/W 0x0000_0000
Base Address
− 0xFFFF_FF00
