I/O PORTS S3F401F_UM_REV1.00
8-12
PORT1 Control Register PCON1L (0x00C) Access: Read/Write
31 30 29 28 27 26 25 24
P1.15 [31:30] P1.14[29:28] P1.13[27:26] P1.12[25:24]
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
23 22 21 20 19 18 17 16
P1.11[23:22] P1.10[21:20] P1.9[19:18] P1.8[17:16]
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
15 14 13 12 11 10 9 8
P1.7[15:14] P1.6[13:12] P1.5[11:10] P1.4[9:8]
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
7 6 5 4 3 2 1 0
P1.3[7:6] P1.2[5:4] P1.1[3:2] P1.0[1:0]
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
W: Write R: Read -0: 0 After reset -1: 1 After reset -U: Undefined after reset
P1.0 PORT 1.0
00 = Input Mode General IO port Schmitt-trigger
01 = Output Mode General IO port
−
10 = UARTRX0 UART0 Input port
−
11 = INT0 Interrupt Signal input port
−
P1.1 PORT 1.1
00 = Input Mode General IO port Schmitt-trigger
01 = Output Mode General IO port
−
10 = UARTTX0 UART0 output port
−
11 = INT1 Interrupt Signal input port
−
P1.2 PORT 1.2
00 = Input Mode General IO port Schmitt-trigger
01 = Output Mode General IO port
−
10 = UARTRX1 UART1 input port
−
11 = INT2 Interrupt Signal input port
−
P1.3 PORT 1.3
00 = Input Mode General IO port Schmitt-trigger
01 = Output Mode General IO port
−
10 = UARTTX1 UART1 output port
−
11 = INT3 Interrupt Signal input port
−
