S3F401F_UM_REV1.00 INVERTER MOTOR CONTROLLER (IMC)
6-25
5. REGISTERS DESCRIPTION
Table 6-1. IMC Special Function Registers
Offset Address Register Description R/W Reset Value
0x000 IMCON0 Inverter motor control register 0 R/W 0x0000_0000
0x004 IMCON1 Inverter motor control register 1 R/W 0x0000_0000
0x008 IMSTATUS Inverter motor status register R/W 0x0000_0000
0x00C ADCSTARTSEL ADC start signal select register R/W 0x0000_0000
0x010 IMCNT 16bit Inverter motor counter register R 0x0000_0000
0x014 TOPCMP 16bit Top compare register R/W 0x0000_0000
0x018 PACMPR 16bit Phase A compare register of rising R/W 0x0000_0000
0x01C PACMPF 16bit Phase A compare register of falling R/W 0x0000_0000
0x020 PBCMPR 16bit Phase B compare register of rising R/W 0x0000_0000
0x024 PBCMPF 16bit Phase B compare register of falling R/W 0x0000_0000
0x028 PCCMPR 16bit Phase C compare register of rising R/W 0x0000_0000
0x02C PCCMPF 16bit Phase C compare register of falling R/W 0x0000_0000
0x030 ADCCMPR0 16bit ADC start compare register of rising 0 R/W 0x0000_0000
0x034 ADCCMPF0 16bit ADC start compare register of falling 0 R/W 0x0000_0000
0x038 ADCCMPR1 16bit ADC start compare register of rising 1 R/W 0x0000_0000
0x03C ADCCMPF1 16bit ADC start compare register of falling 1 R/W 0x0000_0000
0x040 ADCCMPR2 16bit ADC start compare register of rising 2 R/W 0x0000_0000
0x044 ADCCMPF2 16bit ADC start compare register of falling 2 R/W 0x0000_0000
0x048 DTCMP 16bit Dead-time compare register R/W 0x0000_0000
Base Address
− IMC0: 0xFF02_0000
− IMC1: 0xFF02_4000
