INTERRUPT CONTROLLER S3F401F_UM_REV1.00
7-14
INTERRUPT PENDING2 Register INTPND2 (0x014) Access: Read/Write
31 30 29 28 27 26 25 24
− − − − − −
SW0_PND BT_PND
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
23 22 21 20 19 18 17 16
SSP_ERR1_PND SSP_RX1_PND SSP_TX1_PND SSP_ERR0_PND SSP_RX0_PND SSP_TX0_PND TMC5_PND TOF5_PND
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
15 14 13 12 11 10 9 8
TMC4_PND TOF4_PND TMC3_PND TOF3_PND TMC2_PND TOF2_PND TMC1_PND TOF1_PND
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
7 6 5 4 3 2 1 0
TMC0_PND TOF0_PND UERR1_PND UTX1_PND URX1_PND UERR0_PND UTX0_PND URX0_PND
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
W: Write R: Read -0: 0 After reset -1: 1 After reset -U: Undefined after reset
Interrupt Pending Register 2
0 = The interrupt has not been requested READ
1 = The interrupt source has asserted the interrupt request
0 = No effect, keeping current status WRITE
1 = Clear pending bit
URX0_PND 0x0000_0001 TOF5_PND 0x0001_0000
UTX0_PND 0x0000_0002 TMC5_PND 0x0002_0000
UERR0_PND 0x0000_0004 SSP_TX0_PND 0x0004_0000
URX1_PND 0x0000_0008 SSP_RX0_PND 0x0008_0000
UTX1_PND 0x0000_0010 SSP_ERR0_PND 0x0010_0000
UERR1_PND 0x0000_0020 SSP_TX1_PND 0x0020_0000
TOF0_PND 0x0000_0040 SSP_RX1_PND 0x0040_0000
TMC0_PND 0x0000_0080 SSP_ERR1_PND 0x0080_0000
TOF1_PND 0x0000_0100 BT_PND 0x0100_0000
TMC1_PND 0x0000_0200 SW0_PND 0x0200_0000
TOF2_PND 0x0000_0400
TMC2_PND 0x0000_0800
TOF3_PND 0x0000_1000
TMC3_PND 0x0000_2000
TOF4_PND 0x0000_4000
TMC4_PND 0x0000_8000
