S3F401F_UM_REV1.00 INVERTER MOTOR CONTROLLER (IMC)
6-33
Inverter Motor Control Register 1 (Continued) IMCON1 (0x000) Access: Read/Write
PWMxD2LEVEL PWMxD2 Output Level Selection Bit
0 = Low level
1 = High level
PWMxD1 LEVEL PWMxD1 Output Level Selection Bit
0 = Low level
1 = High level
PWMxD0 LEVEL PWMxD0 Output Level Selection Bit
0 = Low level
1 = High level
PWMxU2LEVEL PWMxU2 Output Level Selection Bit
0 = Low level
1 = High level
PWMxU1LEVEL PWMxU1 Output Level Selection Bit
0 = Low level
1 = High level
PWMxU0LEVEL PWMxU0 Output Level Selection Bit
0 = Low level
1 = High level
PWMxD2DT PWMxD2 Dead-time Insert Bit: before PWM output disable by setting PWMxD2EN
0 = No insertion
1 = Insertion
PWMxD1DT PWMxD1 Dead-time Insert Bit: before PWM output disable by setting PWMxD1EN
0 = No insertion
1 = Insertion
PWMxD0DT PWMxD0 Dead-time Insert Bit: before PWM output disable by setting PWMxD0EN
0 = No insertion
1 = Insertion
PWMxU2DT PWMxU2 Dead-time Insert Bit: before PWM output disable by setting PWMxU2EN
0 = No insertion
1 = Insertion
PWMxU1DT PWMxU1 Dead-time Insert Bit: before PWM output disable by setting PWMxU1EN
0 = No insertion
1 = Insertion
PWMxU0DT PWMxU0 Dead-time Insert Bit: before PWM output disable by setting PWMxU0EN
0 = No insertion
1 = Insertion
