Effect parameters |505
b [R]Pre Delay [msec] 0…200 Sets the delay time of the reverb sound
and gate control signal
c [R]EQ Trim 0…100 Sets the EQ input level
Reverb Balance 0…100 Sets the reverb effect balance
d [R]PreLEQ Fc Low,
Mid-Low
Selects the cutoff frequency (low or
mid-low) of the low-range equalizer
Pre HEQ Fc High,
Mid-High
Selects the cutoff frequency (high or
mid-high) of the high-range equalizer
e [R]PreLEQ Gain [dB] –15.0…+15.0 Sets the gain of Low EQ
Pre HEQ Gain [dB] –15.0…+15.0 Sets the gain of High EQ
GATE
f [G]Envelope Select D-mod, Input Switches between modulation source
control and input signal control
Src Off…Tempo Selects the modulation source that con-
trols the gate when Envelope Select is
set to D-mod
g [G]Input Reverb Mix 0…100 Sets the balance between the dry and
reverb sounds of the gate control signal
Threshold 0…100 Sets the gate threshold level
h [G]Polarity +, – Switches between non-invert and invert
of the gate on/off state
i [G]Attack 1…100 Sets the attack time
Release 1…100 Sets the release time
j Wet/Dry Dry, 1:99…99:1,
Wet Balance between the wet and dry signal
Src Off…Tempo See DMS (Dynamic Modulation Source)
Amt –100…+100 Amount of modulation source
f: [G]Envelope Select
f: Src
g: [G]Input Reverb Mix
g: Threshold
The “[G]Envelope Select” parameter enables you to select whether turning
the gate on and off is triggered by the input signal level or controlled directly
by the modulation source. You can select from Off to Tempo for the Src pa-
rameter to specify the modulation source.
