KORG PA4X 76 User Manual
Page 1069
Specs |1065
KOrG Pa4X
Features
Storage
Hard Disk Drive
Pa4X-76: standard
Pa4X-61: optional, user installable; HDIK-3 hard disk installation kit
required
microSD card (card not included); rear panel slot with plastic cover
USB external drives (drive not included); 1 front panel port, 1 rear
panel port
Display
7” Wide capacitive color TouchView™ TFT display
Clock
Internal System Clock
Power Consumption
100-240 Volts, 50/60 Hz
< 0.5 Watt in standby / 16 Watt normal / 35 Watt with PaAS installed
Dimensions
(W x D x H)
Pa4X-76: 1,192 x 364.4 x 125.56 mm / 46.93” x 14.35” x 4.94”
Pa4X-61: 980 x 364.4 x 125.56 mm / 38.58” x 14.35” x 4.94”
(without music stand, display fully lowered)
Weight
Pa4X-76: 16.3 kg / 35.93 lbs
Pa4X-61: 13.9 kg / 30.64 lbs
Accessories
AC Power Cable, Music Stand, Quick Guide manual
Accessory Disc, containing the Video Manuals, additional manuals
and software utilities
Options
PaAS Amplification System
ST-SV1 BK Keyboard Stand
HDIK-3 Hard Disk Installation Kit (for Pa4X-61 only)
EC-5 Multiswitch Pedal
EXP-2 Foot Controller
XVP-10 Expression/Volume Pedal
DS-1H Damper Pedal (supports half-pedaling)
PS-1 Pedal Switch
PS-3 Pedal Switch
Specifications and appearance are subject to change without notice for im-
provement.
