Editing the Sounds |393
Equalizing the Sound
You can use a three-band, semi-parametric equalizer on each oscillator.
▪
Go to the
Sound > Basic > EQ
page.
Activating the EQ
▪
Select the
Enable
checkbox to activate the equalizer on the selected oscil-
lator.
Trimming and programming the EQ
▪
Use the
Trim
knob to limit the level of the signal passing through the equal-
izer (0…99). Extreme equalization values can overload the audio circuits and
lead to distortion. This control lets you set equalization as desired, and at the
same time avoid overloading.
▪
Use the
EQ controls
to create the equalization curve.
EQ Control
Meaning
Value
Low Gain
Low frequencies equalization. This is a shelving
curve filter.
-18…+18dB
Mid (Middle) Gain
Middle frequencies equalization. This is a bell
curve filter.
-18…+18dB
Mid (Middle) Freq
Centre frequency of the middle frequencies
equalization.
0.100…10kHz
Hi (High) Gain
High frequencies equalization. This is a shelving
curve filter.
-18…+18dB
