SCPI Command Overview
SCPI (Standard Commands for Programmable Instruments) is standardized instrument programming
language that is based on the standard IEEE488.1 and IEEE488.2 and conforms to various standards (such
as the floating point operation rule in IEEE754 standard, ISO646 7-bit coded character for information
interchange (equivalent to ASCll programming). This chapter describes the syntax, symbol, parameter and
abbreviation rules of the SCPI commands.
Syntax
SCPI commands present a hierarchical tree structure and have multiple sub-systems, each of which
contains a root keyword and one or more sub-keywords. The command string usually begins with ":"; the
keywords are separted by ":" and are followed by the parameter settings available; "?" is added at the end
of the command string to indicate query; space is used to separate the command and parameter.
For example,
:SYSTem:COMMunication:LAN:IP:ADDress
:SYSTem:COMMunication:LAN:IP:ADDress?
SYSTem is the root keyword of the command above. COMMunication, LAN, IP and ADDress are the
second-level, third-level, forth-level and fifth-level keywords separately. The command string begins with
":" which is also used to separate the multi-level keywords. denotes the parameter available for
setting. "?" denotes query and DSG3000 returns the response information (the output value or internal
setting value of the instrument) when recieving a query command. The
command :SYSTem:COMMunication:LAN:IP:ADDress and prarameter are separated by a space.
"," is generally used for separating different parameters contained in the same command, for example,
[:SOURce]:SWEep:LIST:ADDList ,,
Symbol Description
The following four symbols are not the content of SCPI commands but are usually used to describe the
parameters in the commands.
1. Braces { }
Multiple optional parameters are enclosed in the braces and one of the parameters must be selected
when sending the command.
2. Vertical Bar |
The vartical bar is used to separate multiple parameters. When you send a command, one of the
parameters should be selected. For example, :SYSTem:LANGuage CHINese|ENGLish.
3. Square Brackets [ ]
The content (such as keywords) enclosed in the square brackets could be omitted. If the content is
omitted, the instrument would set it to the default. For example, [:SOURce]:PHASe:STEP[:INCRement]?
Sending any of the four commands below can generate the same effect.
:PHASe:STEP?
:PHASe:STEP:INCRement?
:SOURce:PHASe:STEP?
:SOURce:PHASe:STEP:INCRement?
4. Triangle Brackets < >
The parameter enclosed in the triangle brackets must be replaced by an effective value. For example,
send the [:SOURce]:FREQuency command in :FREQuency 4MHz form.
