Telescoping Base Stands
These stands are available with either fixed feet or casters. The height of these stands
is set before installation of the Logic. The height can be set at 27.5 to 33.5 inches in 1-
inch intervals, providing a work surface height of 30.0 to 36.0 inches. The Base Stands
for each Logic model are listed in Table 3-2 below.
Table 3-2
Width
Base Stand w/Feet
Model #
Base Stand w/wheels
Model #
3' 3730300
3730310
4' 3730400
3730410
5' 3830500
3830510
6' 3730600
3730610
1. Before positioning the Telescoping Base Stand in its final location, adjust the final
height of the stand. A part bag containing the mounting bolts for the Purifier is
strapped to the base stand. Remove and save it.
2. Select the height of the stand and slide four (4) leg extensions into base stand
corner posts and attach with 2 ¼ inch long bolt, flatwasher, lockwasher and nut.
Ensure that the same height hole is selected for each leg. Tighten the leg bolts
securely. See Figure 3-3.
Figure 3-3
