Figure 7-25
9. To replace the motor/blower assembly, reverse the above procedure.
Note: During reinstallation of the blower assembly, angle the rear blower
bracket into the plenum blower opening. Make sure to engage the rear
blower bracket inside the plenum blower hole. After reinstalling and
tightening the three blower bolts, ensure that the rear blower bracket is
correctly engaged by trying to move the blower assembly. If it is rigidly
captured on the plenum, then the rear bracket is properly engaged. If the
rear of the blower assembly moves freely, then the blower must be
reinstalled.
10. Continue the reassembly. Plug in the cabinet and recertify it before use.
Work Surface Removal
Note: The work surface of the cabinet must be thoroughly decontaminated before
removing it.
1. Lift the front edge of the work surface straight up by grasping the knob handles at
either front corner.
2. Pull the work surface straight out, letting its rear edge rest on the center support
underneath.
3. Reinstall the work surface by resting the bottom on the center rail while pushing it
back into the cabinet. Be sure to engage the tabs on the back corners of the work
surface with the slots on the rear wall of the work area.
