QuickChart – PuriCare Procedure Stations
Model
34800
34802
34512
34810
34812
Type
A2 A1 A1 A2 A1
Cabinet
Size
(in
feet) 4 4 5 6 6
Sash
Opening
(inches) 10 12 12 10 12
Starting Serial #
0705_
0705_
0705_ 0705_
0705_
HEPA Filter Leak Test Data
Air Displacement (CFM)
794
783
979
1189
1173
Laskin
Nozzles
needed 2 2 2 2 2
Theoretical aerosol conc. (ug/l)
1
34 34 28 23 23
Actual aerosol conc. (ug/l)
2
18 18 16 15 15
Nominal Speed Control Setting
83
80
80-90
79
76
Downflow Data
Nominal
Avg.
Downflow
(FPM) 55+/-5 55+/-5 55+/-5 55+/-5 55+/-5
Downflow test grid # of points
24
24
30
36
36
Test Grid (# rows x # columns)
3 x 8
3 x 8
3 x 10
3 x 12
3 x 12
Test Grid Data (in inches)
Grid distance from back & sides
6.0
6.0
6.0 6.0
6.0
Distance between rows 5.55 5.55 5.55 5.55 5.55
Distance between columns
5.21 5.21 5.39 5.50 5.50
Inflow Data
Nominal Average Inflow (FPM)
105+/-5
85+/-5
85+/-5
105+/-5
85+/-5
Sash Open Area (Sq. Ft) 3.37 4.04 5.04 5.03 6.04
Nominal Avg. Exhaust Vol. (CFM)
354 344 429 529 514
Avg. Exhaust Vol. Range (CFM)
337-370
323-364
403-454
503-554
483-544
Secondary Inflow Data
3
Restricted Sash Opening (inches)
4
3
3 2.25 4.25 4.25
Sensor distance (inches)
5
4 4 3.25 4 4
# of Test points
8
8
10
12
12
Test point location
*
*
*
*
*
Nominal Avg. Inflow Vel. (FPM)
354
344
429
289
281
Avg.
Inflow
Vel.
Range
(FPM) 337-370 323-364 403-454 275-302 264-297
Correction Factor (CF)
1
1
1
1.83
1.83
Average Inflow Volume Range
(AIV) (Avg. velocity x CF)
337-370 323-364 403-454 503-553 483-544
Sash Open Area (Sq. Ft) 3.37 4.04 5.04 5.03 6.04
Inflow Velocity Range
(AIV / Sash open area)
100-110 80-90 80-90 100-110 80-90
Supply HEPA Data
Width
(inches)
48 48 60 72 72
Depth (inches)
18
18
18
18
18
Height (inches)
6
3.06
3.06
3.06
3.06
3.06
Performance
(CFM)
445 445 555 665 665
Performance (Pressure in. H
2
O) .43-.57 .43-.57 .43-.57 .43-.57 .43-.57
Labconco
P/N
3838401 3838401 3838402 3838403 3838403
Filtration Group P/N
42546L 42546L 42663L 42666L 42666L
AAF P/N
907-543-
202
907-543-
202
907-543-
203
907-543-
204
907-543-
204
