QuickChart – PuriCare Procedure Stations (cont)
Exhaust HEPA Data
34800
34802
34512
34810
34812
Width
(inches)
26 26 36 48 48
Depth (inches)
18
18
18
18
18
Height (inches)
6
5.88
5.88
5.88
5.88
5.88
Performance
(CFM)
353 353 441 529 529
Performance (Pressure in. H
2
O)
.23-.37 .23-.37 .23-.37 .23-.37 .23-.37
Labconco
P/N
3838501 3838501 3838502 3838503 3838503
Filtration Group P/N
42547L
42547L
42673L 41727L 41727L
AAF P/N
907-543-
206
907-543-
206
907-543-
207
907-543-
208
907-543-
208
Motor/Blower Data
Labconco P/N
7
3832201
3832201
3832203
3832203
3832203
Motor HP
½
½
¾ ¾ ¾
Blower Size (inches)
10 x 8
10 x 8
10 x 8
10 x 8
10 x 8
Nominal
Speed
Control
Setting
85 85 85 81 81
Fluorescent Lamp Data
Fluorescent Lamps (2 each)
F32T8
TL741
F32T8
TL741
F40T8
SP41
F40T8
SP41
F40T8
SP41
Fluor. Lamp Labconco Part #
9721900
9721900
9721903
9721903
9721903
Fluor. Ballast Labconco Part #
3838100
3838100
3838100
3838100
3838100
Fluor. Ballast Robertson Part #
ISL332T
8MVW
ISL332T
8MVW
ISL332T
8MVW
ISL332T
8MVW
ISL332T
8MVW
Circuit Breaker Data
100V/115V
Motor/Light Breaker Rating, Amps
8 8 10 10 10
Motor/Light Breaker, Labconco #
1327208
1327208
1327201
1327201
1327201
Motor/Light Breaker,
Mechanical Products Part #
1600-062-
080-007
1600-062-
080-007
1600-062-
100-007
1600-062-
100-007
1600-062-
100-007
Outlet
Breaker
Rating,
Amps
5 5 5 5 5
Outlet Breaker, Labconco #
1327204
1327204
1327204
1327204
1327204
Outlet Breaker, Mechanical
Products Part #
1600-062-
050-007
1600-062-
050-007
1600-062-
050-007
1600-062-
050-007
1600-062-
050-007
Circuit Breaker Data 230V
Motor/Light Breaker Rating, Amps
4 4 5 5 5
Motor/Light Breaker, Labconco #
1327209
1327209
1327204
1327204
1327204
Motor/Light Breaker,
Mechanical Products Part #
1600-062-
040-007
1600-062-
040-007
1600-062-
050-007
1600-062-
050-007
1600-062-
050-007
Outlet
Breaker
Rating,
Amps
3 3 3 3 3
Outlet Breaker, Labconco #
1327200
1327200
1327200
1327200
1327200
Outlet Breaker, Mechanical
Products Part #
1600-062-
030-007
1600-062-
030-007
1600-062-
030-007
1600-062-
030-007
1600-062-
030-007
Canopy Data
Labconco Canopy P/N
3858701
3858701
3858702 3858703
3858703
Canopy Alarm Setpoint Vol. (CFM)
8
337-370 323-364 403-454 503-554 483-544
Nominal
Canopy
Vol.
(CFM) 424 413 558 687 668
Canopy
Vol.
Range
(CFM) 404-444 388-437 524-590 654-720 628-707
Canopy Data 2
nd
Generation
9
Labconco Canopy P/N
3898001
3898001
3898002
3898003
3898003
Canopy Slot Area (F
2
)
0.186 0.186 0.236 0.304 0.304
Nominal Canopy Slot Velocity
(FPM)
10
400 400 315 330 330
Nominal Canopy Slot Volume (CFM)
75 75 75 100 100
Canopy Slot Velocity
Alarm Setpoint (FPM)
10
100 100 100 100 100
Total
Exhaust
Volume
(CFM) 412-445 398-439 478-529 603-654 583-644
Canopy Vacuum (In. H
2
O) .15-.25
.15-.25
.15-.25
.15-.25 .15-.25
