QuickChart - Logic Type B2 Biohazard Cabinets (cont)
Exhaust HEPA Filter Leak Test Data
Air Displacement (CFM) 723 1083
Laskin Nozzles needed 2 2
Theoretical aerosol conc. (ug/l)
1
38 25
Actual aerosol conc. (ug/l)
2
21 17
Exhaust HEPA Data
Width (inches) 26 48
Depth (inches) 18 18
Height (inches)
10
5.88 5.88
Performance (CFM) 353 529
Performance (Pressure in. H
2
O) .23-.37 .23-.37
Labconco P/N 3838501 3838503
Filtration Group P/N 42547L 41727L
AAF P/N 907-543-
206
907-543-
208
Motor/Blower Data
Labconco P/N
11
3832204 3832205
Motor HP ½ ½
Blower Size (inches) 10 x 8 10 x 8
Nominal Speed Control Setting 74 73
Fluorescent Lamp Data
Fluorescent Lamps (2 each) F32T8
TL741
F40T8
SP41
Fluor. Lamp Labconco Part # 9721900 9721903
Fluor. Ballast Labconco Part # 3838100 3838100
Fluor. Ballast Robertson Part # ISL332T8
MVW
ISL332T8
MVW
Circuit Breaker Data 100V/115V
Motor/Light Breaker Rating, Amps 8 10
Motor/Light Breaker, Labconco Part # 1327208 1327201
Motor/Light Breaker, Mechanical Products Part # 1600-062-
080-007
1600-062-
100-007
Outlet Breaker Rating, Amps 5 5
Outlet Breaker, Labconco Part # 1327204 1327204
Outlet Breaker, Mechanical Products Part # 1600-062-
050-007
1600-062-
050-007
Circuit Breaker Data 230V
Motor/Light Breaker Rating, Amps 4 5
Motor/Light Breaker, Labconco Part # 1327209 1327204
Motor/Light Breaker, Mechanical Products Part # 1600-062-
040-007
1600-062-
050-007
Outlet Breaker Rating, Amps 3 3
Outlet Breaker, Labconco Part # 1327200 1327200
Outlet Breaker, Mechanical Products Part # 1600-062-
030-007
1600-062-
030-007
