QuickChart - Logic Type B2 Biohazard Cabinets
Model 34410
34610
Type
B2
B2
Cabinet Size (in feet)
4
6
Sash Opening (inches)
8
8
Starting Serial #
0705_
0705_
Downflow Data
Nominal Avg. Downflow (FPM)
55+/-5
55+/-5
Downflow test grid # of points
24
36
Test Grid (# rows x # columns)
3 x 8
3 x 12
Test Grid Data (in inches)
Grid distance from back & sides
6.0
6.0
Distance between rows
5.75
5.75
Distance between columns
5.21
5.50
Inflow Data
Nominal Average Inflow (FPM)
105+/-5
105+/-5
Sash Open Area (Sq. Ft)
2.69
4.03
Nominal Avg. Inflow Vol. (CFM)
283 +/-13
423+/-20
Avg. Inflow Vol. Range (CFM)
269-296
403-443
Secondary Inflow Data
3
Restricted Sash Opening (inches)
4
3
4.25
Sensor distance (inches)
5
4
4
# of Test points
8
12
Test point location
*
*
Nominal Avg. Inflow Vel. (FPM)
283
212
Avg. Inflow Vel. Range (FPM)
269-296
202-222
Correction Factor (CF)
1
2
Average Inflow Volume Range (AIV) (Avg. velocity x CF)
269-296
403-443
Sash Open Area (Sq. Ft)
2.69
4.03
Inflow Velocity Range (AIV / Sash open area)
100-110
100-110
Exhaust Data
DIM Exhaust Volume (CFM)
6
665
998
Traverse Exhaust Volume (CFM)
7
810
1218
Differential Pressure (in. H
2
0)
8
1.4
1.4
Exhaust (Inflow) Alarm Data
Alarm Setpoint (CFM Inflow)
9
150 +/- 5
223 +/- 5
Supply HEPA Filter Leak Test Data
Air Displacement (CFM)
445
665
Laskin Nozzles needed
1
1
Theoretical aerosol conc. (ug/l)
1
30
20
Actual aerosol conc. (ug/l)
2
15
12
Nominal Speed Control Setting
70
70
Supply HEPA Data
Width (inches)
48
72
Depth (inches)
18
18
Height (inches)
10
3.06
3.06
Performance (CFM)
445
665
Performance (Pressure in. H
2
O) .43-.57
.43-.57
Labconco P/N
3838401
3838403
Filtration Group P/N
42546L
42666L
AAF P/N
907-543-
202
907-543-
204
