Page 58
Introducing and Using the Graphical User Interface
46
FTB-8100 Series Transport Blazer
Keyboard Usage
Keyboard Usage
The GUI pops up different keyboards to modify data. Following are the
usual keyboard keys:
³
Left arrow: Moves the cursor one position to the left.
³
Right arrow: Moves the cursor one position to the right.
³
Del: Deletes the value at the cursor position.
³
Back: Deletes the value preceding the cursor position.
³
Help: Displays the help information related to the keyboard usage.
It is also possible to navigate through the help information.
³
OK and Enter: Completes data entry.
³
Cancel: Closes the keyboard and discards the keyboard entry.
³
Binary keyboard: Allows entering 0 and 1 values.
