Page 37
Introducing and Using the Graphical User Interface
SONET/SDH Application
25
Main Window
Main Window
Test Setup and Tabs Display Area
The Test Setup window is displayed by default when the SUI is launched,
allowing the creation of the test case by passing through the signal
structure. This area is also used to display the test configuration and result
tabs. Refer to Introducing the Test Setup on page 54 for more information
on Test Setup.
Application Name and Power Indicator
Displays the Compact SSA software application name and provides the
battery and/or DC power source indicator.
Application name and
power indicator
Test Setup and tabs display area
Main Menu
Global Test Status
Print Screen
Exit
Help
Test Controls
