Summary Tabs
SONET/SDH Application 109
Test Logger
Logger Table
An event is automatically listed in the logger and saved on the hard drive in
case a power failure condition occurs.
The logger is cleared when one of the following conditions is met:
³
A test case is stopped and restarted.
³
The test case is cleared.
³
When pressing (Reset).
Events are listed by ID - Date/Time by default. Events can also be sorted by
Data Path or Event by pressing on the corresponding column title.
³
ID: Indicates the Event number. Events are sequentially numbered.
³
Date/Time: Indicates the date and time the Alarm/Error condition has
been detected.
³
Data Path: Indicates the origin of the alarm/error. [P1] and [P2] in the
data path represent respectively the Port 1 and Port 2.
³
Event: Indicates the alarm/error type.
³
Duration: Indicates the number of seconds (day:hour:minute:second
format) within which the alarm/error occurred.
Note: In the Duration column, Pending indicates that the alarm/error condition
persists or was persisting when the test was stopped.
