EXFO FTB-8100 Series Transport Blazer for FTB-200 User Manual
Page 276
SDH Tabs
264
FTB-8100 Series Transport Blazer
Multiplex Section RX (SDH)
For STM-4: The MS-REI error is declared when the M1 byte located in
the STM-1 channel 3 (timeslot #7) indicates that one or more BIP
violations have been detected.
For STM-16: The MS-REI error is declared when the M1 byte located in
the STM-1 channel 3 (timeslot #7) indicates that one or more BIP
violations have been detected.
M1, bits
234 5678
Indicates
000 0000
0 BIP violation
000 0001
1 BIP violation
000 0010
2 BIP violations
:
:
110 0000
96 BIP violations
110 0001
0 BIP violation
:
:
111 1111
0 BIP violation
M1
Indicates
0000 0000
0 BIP violation
0000 0001
1 BIP violation
0000 0010
2 BIP violations
:
:
1111 1111
255 BIP violations
