Physical Interfaces and LEDs
16 FTB-8100 Series Transport Blazer
Port Availability on FTB-8100 Series Module
Port Availability on FTB-8100 Series Module
The following table shows the list of available ports as well as a description
and signals supported for each module. For Ethernet and Fibre Channel
ports, refer to the “Ethernet and Fibre Channel Application” user guide.
Port labelled Description Supported signal(s) Module
155M-2.5G Optical IN/OUT port
small form factor
pluggable (SFP)
OC-3/STM-1, OC-12/STM-4,
OC-48/STM-16
FTB-8115
155M-2.7G Optical IN/OUT port
small form factor
pluggable (SFP)
OC-3/STM-1, OC-12/STM-4,
OC-48/STM-16, OTU1
FTB-8120
FTB-8120NG
FTB-8130
FTB-8130NG
100M-4.25G Optical IN/OUT port
small form factor
pluggable (SFP)
OC-3/STM-1, OC-12/STM-4,
OC-48/STM-16, OTU1, Ethernet
100Mbps, Ethernet 1000Mbps, FC
1x, FC 2x, FC 4x
FTB-8120NGE
FTB-8130NGE
10G-11.3G Optical IN/OUT port
10G small form factor
pluggable (XFP)
OC-192/STM-64, OTU2, OTU2e,
OTU1e, OTU1f, OTU2f,
Ethernet 10Gig (FTB-8130NGE),
FC 10x (FTB-8130NGE)
FTB-8130
FTB-8130NG
FTB-8130NGE
2M/8M/34M/
45M/52M/
140M/155M, or
2M-155M
Electrical IN/OUT port
BNC
E1/2M, E2/8M, E3/34M, DS3/45M,
STS-1e/STM-0e/52M, E4/140M,
STS-3e/STM-1e/155M
FTB-8105/15/
20/30
1.5M/2M Electrical IN/OUT port
Bantam
DS1/1.5M, E1/2M FTB-8100
Series
1.5M/2M Electrical port RJ-48C DS1/1.5M, E1/2M FTB-8100
Series
AUX Electrical port BNC DS1/1.5M/E1/2M/2 MHz signal for
external clock synchronization, or
DS1/DS3 signal for Dual RX test.
FTB-8100
Series
