SDH Tabs
280 FTB-8100 Series Transport Blazer
HOP OH TX/RX (SDH)
³
H4: Multiframe Indicator. This byte is not programmable with LOP or
VCAT.
³
F3: User Channel
³
K3: Automatic Protection Switching (APS)
³
N1: (Network operator byte) Tandem Connection Monitoring (TCM)
Path Signal Label (C2)
The C2 byte is allocated to indicate the content of the VC, including the
status of the mapped payloads.
C2
(Hex.)
Description
C2
(Hex.)
Description
00
a
a. These values cannot be selected as Expected Path Signal Label.
Unequipped or
supervisory-unequipped
17 Reserved (SDL self-synch scrambler)
01 Reserved (Equipped -
Non-Specific)
18 Mapping of HDLC/LAPS
02 TUG Structure 19 Reserved (SDL set-reset scrambler)
03 Locked TU-n 1A Mapping of 10 Gbps Ethernet (IEEE 802.3)
04 Asynchronous Mapping of
34M/45M in C-3
1B GFP
05 Experimental Mapping 1C Mapping 10 Gbps FC
12 Asynchronous Mapping of
140M in C-4
20 Asynchronous Mapping of ODUk
13 ATM Mapping CF Reserved (obsolete HDLC/PPP framed)
14 MAN DQDB FE Test Signal, ITU-T 0.181 specific mapping
15 FDDI [3]-[11] Mapping FF
a
VC-AIS (TCM)
16 Mapping of HDLC/PPP
