SONET/SDH Application 11
3 Getting Started
If the FTB-8100 Series Transport Blazer has been purchased at the same
time as the FTB-200, the FTB-8100 Series module is pre-installed with the
appropriate Compact ToolBox/ToolBox CE software version.
Compact ToolBox/ToolBox CE Installation
Compact ToolBox or ToolBox CE is the baseline software and thus needs to
be installed on the FTB-200 before using the FTB-8100 Series module.
Note: Refer to the FTB-200 platform user guide for more information on Compact
ToolBox/ToolBox CE installation procedure.
Inserting and Removing Test Modules
Note: Refer to the FTB-200 platform user guide for more information on how to
insert a module into the FTB-200 or to remove a module from the FTB-200.
Turning the Unit On
Turn on the FTB-200. Refer to the FTB-200 platform user guide for more
information.
C
AUTION
Never insert or remove a module while the FTB-200 is turned on.
This will result in immediate and irreparable damage to both the
module and unit.
W
ARNING
When the laser safety LED is flashing on the SONET/SDH Application,
at least one of your modules is emitting an optical signal. Please
check all modules, as it might not be the one you are currently
using.
