Report Generator
482 FTB-8100 Series Transport Blazer
Transferring the Generated Test Report to the PC
Transferring the Generated Test Report to
the PC
Transfer the saved report to the PC
1. Local memory (FTB-200): If the report has been saved to the FTB-200
local folder, the report file need to be transferred to the PC using one of
the following methods:
1a. Network drive: Connect the FTB-200 and the PC to the network
and transfer the file to a network drive or directly on a shared
folder on the PC.
1b. USB connection (ActiveSync): Establish an ActiveSync
connection between the PC (USB host) and the FTB-200 (USB
client) using the supplied client/host USB cable. ActiveSync is
available on the supplied ToolBox CE CD; click Utilities and
Viewers and click Microsoft ActiveSync 4.1 to install it.
The default FTB-200 local folder is \Data\My Documents\folder\Report.
The following table lists the corresponding folder for each supported
model/application.
2. USB drive or Compact Flash: If the report has been saved on a
removable drive/media, plug the USB drive or the compact flash to the
PC.
3. Network drive: If the report has been saved on a network drive,
connect the PC to the network and retrieve the file from the network
drive.
Model Application Folder
FTB-8105/FTB-8115/
FTB-8120/FTB-8120NG/
FTB-8130/FTB-8130NG
SONET/SDH Analyzer SonetSdhAnalyzerG2
FTB-8120NGE/ FTB-8130NGE Packet Analyzer PacketAnalyzer
SONET/SDH Analyzer SonetSdhAnalyzerG2
