SDH Tabs
270
FTB-8100 Series Transport Blazer
Multiplex Section APS/Advanced OH TX/RX (SDH)
³
Operation Mode: Bits 6 through 8 of the K2 byte. The default
setting is Reserved (000) for Linear switching mode and Idle for
Ring switching mode.
SS Bits (H1)
³
Bits 5 and 6 of the H1 byte represent the SS bits.
Bits 6 to 8
Linear mode
Ring mode
000
Reserved
Idle
001
Reserved
Bridged
010
Reserved
Bridged and Switched
011
Reserved
Extra Traffic - Protection
100
Unidirectional
Reserved
101
Bidirectional
Reserved
110
MS-RDI
MS-RDI
111
MS-AIS
MS-AIS
SS Bits
Description
00
SONET
01
Undefined
10
SDH
11
Undefined
