Information – EXFO FTB-8100 Series Transport Blazer for FTB-200 User Manual
Page 497
Report Generator
SONET/SDH Application
485
Information
Information
The Compact Report Generator allows to edit the following job information
that was entered at the time the report was saved.
³
Job Information: These parameters are used to identify the source of
the report and are not mandatory. Enter the following job information if
required: Job ID, Contractor, Customer, Operator Name, and
Comment. Up to 256 characters are allowed for each parameter.
³
Report Settings: These parameters are used to identify the report and
are not mandatory. Enter the following report information if needed:
Report Title, and Report Header, and Selected Logo (the default
logo is EXFO). Click Browse to select a different logo then, click Open.
Report Format: Select the report file format. Choices are html, csv,
pdf, and txt. The CSV format (spread sheet file format) generates a
report with comma delimiter for English OS and semicolon for other
OS languages. The default setting is html.
