Smart Mode
92
FTB-8100 Series Transport Blazer
Using SmartMode for Alarm/Error Monitoring
Press an LOP tributary then, the following tributary analysis is
displayed.
To select a different tributary or to return to the timeslot analysis,
press the timeslot button.
Tributary indicates the selected timeslot or the number
associated to the virtual tributary or tributary unit.
Error Analysis gives current and history status of the main errors.
Refer to SONET Tabs on page 167 or SDH Tabs on page 249 for the
error descriptions.
Alarm Analysis gives current and history status of the main
alarms. Refer to SONET Tabs on page 167 or SDH Tabs on
page 249 for the alarm descriptions.
Last Alarm Scan Date indicates the date and time of the last
Alarm Scan. The date is only displayed when the Alarm Scan is
stopped.
Path Signal Label (V5) indicates the path signal label of the
selected tributary. Refer to Path Signal Label (V5) on page 211
(SONET) or page 290 (SDH) for more information.
Signal button
Timeslot button
Tributary
