EXFO FTB-8100 Series Transport Blazer for FTB-200 User Manual
Page 29
Physical Interfaces and LEDs
SONET/SDH Application
17
Port Availability on FTB-8100 Series Module
REF OUT
Reference output port
SMA
See Clock Interface Connections
on page 21 for more information.
FTB-8130
FTB-8130NG
FTB-8130NGE
Ethernet
10/100/1000M
a
Electrical Ethernet
port RJ-45
10/100/1000 Mbps (electrical)
FTB-8120NG
FTB-8130NG
FTB-8120NGE
FTB-8130NGE
Gig-E /
ETHERNET
ADD/DROP
a
Optical IN/OUT
Ethernet port small
form pluggable (SFP)
1000 Mbps (optical)
FTB-8120NG
FTB-8130NG
FTB-8120NGE
FTB-8130NGE
a.
Only used when the module is used on the FTB-400/500 platform.
Port labelled
Description
Supported signal(s)
Module
