DSn Tabs
242
FTB-8100 Series Transport Blazer
DS3 FEAC TX
DS3 FEAC TX
The Far-End Alarm and Control signal (FEAC) provides Communication
Channel capability over a DS3 in a network applications using C-bit Parity
configuration.
The DS3 FEAC TX tab is used to configure and send alarms/status
information and control signals (loopback commands) to other network
elements.
Note: The DS3 FEAC tab is available when the DS3 framing is set to C-Bit Parity
(see page 238).
Press Main, Test, DSn/PDH, DS3, and FEAC TX.
Configuration
Enable FEAC: Enables DS3 FEAC codeword configuration and analysis.
