Aution – EXFO FTB-8100 Series Transport Blazer for FTB-200 User Manual
Page 31
Physical Interfaces and LEDs
SONET/SDH Application
19
OTN/OC-N/STM-N Interface Connections
Carefully connect optical fibre cables to the SFP/XFP’s IN and OUT ports.
To ensure good signal quality, make sure that the optical fibre connector is
fully inserted into the optical connector port.
³
LASER red LED: The LASER LED is on when the FTB-8100 Series is
emitting an optical laser signal.
³
RX green LED: The RX LED is on when the FTB-8100 Series is receiving
an optical laser signal.
C
AUTION
To prevent exceeding the maximum input power level please use an
attenuator when a loopback configuration is used.
