EVCO S.p.A. c-pro 3 micro CHIL | Application manual ver. 1.0 | Codice 144CP3CHE104
page 97 of 120
11 LIST OF Modbus® VARIABLES
The application can be controlled via a supervisor, using the Modbus ® protocol. Communication takes place via an RS485 serial
interface, which is already incorporated into the controller.
Addr
Base 0
Addr
Base
1
Name
Valu
e
Min Max Description Mode
0x0100 257 Packed_DI1 0 0 65535
bit00=DI01, bit01=DI02, bit02=DI03, bit03=DI04,
bit04=DI05, bit05=DI06, bit06=DI07, bit07=DI08,
bit08=DI09, bit09=DI10, bit10=DI11, bit11=DI12
R/W
0x0101 258 Packed_DI2 0 0 65535
bit00=DI01, bit01=DI02, bit02=DI03, bit03=DI04,
bit04=DI05, bit05=DI06, bit06=DI07, bit07=DI08,
bit08=DI09, bit09=DI10, bit10=DI11, bit11=DI12
R/W
0x0102 259 PackDI_Logic_1 0 0 65535
bit00=DI01, bit01=DI02, bit02=DI03, bit03=DI04,
bit04=DI05, bit05=DI06, bit06=DI07, bit07=DI08,
bit08=DI09, bit09=DI10, bit10=DI11, bit11=DI12
R/W
0x0103 260 PackDI_Logic_2 0 0 65535
bit00=DI01, bit01=DI02, bit02=DI03, bit03=DI04,
bit04=DI05, bit05=DI06, bit06=DI07, bit07=DI08,
bit08=DI09, bit09=DI10, bit10=DI11, bit11=DI12
R/W
0x0104 261 PackDI_Logic_3 0 0 65535
bit00=DI01, bit01=DI02, bit02=DI03, bit03=DI04,
bit04=DI05, bit05=DI06, bit06=DI07, bit07=DI08,
bit08=DI09, bit09=DI10, bit10=DI11, bit11=DI12
R/W
0x0180 385 PackDO_Logic_1 0 0 65535 R/W
0x0181 386 PackDO_Logic_2 0 0 65535 R/W
0x0182 387 PackDO_Logic_3 0 0 65535 R/W
0x0200 513 Probe_TExtern 0.0
-
3276.8
3276.7 R/O
0x0201 514 Probe_TAux 0.0
-
3276.8
3276.7 R/O
0x0202 515 Probe_TIn_FC 0.0
-
3276.8
3276.7 R/O
0x0203 516 Probe_TIn 0.0
-
3276.8
3276.7 R/O
0x0204 517 Probe_TOut_C1 0.0
-
3276.8
3276.7 R/O
0x0205 518 Probe_TOutSorg_C1 0.0
-
3276.8
3276.7 R/O
0x0206 519 Probe_TCoil_C1 0.0
-
3276.8
3276.7 R/O
0x0207 520
Probe_TGasDischar
ge_C1
0.0
-
3276.8
3276.7 R/O
0x0208 521 Probe_TSuction_C1 0.0
-
3276.8
3276.7 R/O
0x0209 522 Probe_PCond_C1 0.0
-
3276.8
3276.7 R/O
0x020A 523 Probe_PEvap_C1 0.0
-
3276.8
3276.7 R/O
0x020B 524 Probe_PUnique_C1 0.0
-
3276.8
3276.7 R/O
0x020C 525 Probe_TOut_C2 0.0
-
3276.8
3276.7 R/O
0x020D 526 Probe_TOutSorg_C2 0.0
-
3276.8
3276.7 R/O
0x020E 527 Probe_TCoil_C2 0.0
-
3276.8
3276.7 R/O
