EVCO S.p.A. c-pro 3 micro CHIL | Application manual ver. 1.0 | Codice 144CP3CHE104
page 39 of 120
7= PT1000
8= NTC K2
9= NTC K3
PV31 Ts offset 0.0 -10.0 10.0 K CO-V
PV32 Te offset 0.0 -10.0 10.0 K CO-V
PV34 Relay logic N.O. (0) N.O. (0) N.C. (1) CO-V
PV35 DI1 logic N.O. (0) N.O. (0) N.C. (1) CO-V
PV36 DI2 logic N.O. (0) N.O. (0) N.C. (1) CO-V
PV37 DI3 logic N.O. (0) N.O. (0) N.C. (1) CO-V
PV80
Enable Modulating Super-Heat
Setpoint circuit 1
Yes (1) No (0) Yes (1) CO-V
PV81 Max Super-Heat circuit 1 15.0 3.0 25.0 °K CO-V
PV82 Min Super-Heat circuit 1 2.0 1.0 25.0 °K CO-V
PV83 Max discharge super-heat circuit 1 35.0 0.0 50.0 °K CO-V
PV84 Min discharge super-heat circuit 1 5.0 0.0 50.0 °K CO-V
EVDRIVE03 circuit 2
PV41 Setpoint SH (1) 6.0 3.0 25.0 K CO-V
PV42 Setpoint LoSH (1) 2.0 1.0 3.0 K CO-V
PV43 Setpoint HiSH (1) 15.0 10.0 40.0 K CO-V
PV44 Setpoint LOP (1) -40.0 -40.0 40.0 K CO-V
PV45 Setpoint MOP (1) 40.0 -40.0 40.0 K CO-V
PV46 PID –proportional band(1) 7.0 1.0 100.0 K CO-V
PV47 PID –integraltime (1) 120 0 999 sec CO-V
PV48 PID –derivativetime (1) 120 0 999 sec CO-V
PV49 Start-up delay (1) 5 1 255 sec CO-V
PV50 Start-up position (1) 50.00 0.00 100.00 % CO-V
PV51 Setpoint SH (2) 6.0 3.0 25.0 K CO-V
PV52 Setpoint LoSH (2) 2.0 1.0 3.0 K CO-V
PV53 Setpoint HiSH (2) 15.0 10.0 40.0 K CO-V
PV54 Setpoint LOP (2) -40.0 -40.0 40.0 K CO-V
PV55 Setpoint MOP 2) 40.0 -40.0 40.0 K CO-V
PV56 PID –proportional band (2) 7.0 1.0 100.0 K CO-V
PV57 PID –integral time (2) 120 0 999 sec CO-V
PV58 PID –derivative time (2) 120 0 999 sec CO-V
PV59 Start-up delay (2) 5 1 255 sec CO-V
PV60 Start-up position (2) 50.00 0.00 100.00 % CO-V
PV61 Stabilization time 0 0 255 sec CO-V
PV62 Stabilization position 100.00 0.00 100.00 % CO-V
PV63
Operation mode:
0= SH algo
1= Manual
0 0 1 CO-V
PV64 Manual position 0.00 0.00 100.00 % CO-V
PV65
SetSH parameters:
0= set1
1= set2
0 0 1 CO-V
PV66
Relay function:
0=Disabled
1= Enabled:any alarm
2=Enabled:probe error
3= LoSH alarm
4= MOP alarm
5= valve alarm
6 0 8 CO-V
