EVCO S.p.A. c-pro 3 micro CHIL | Application manual ver. 1.0 | Codice 144CP3CHE104
page 9 of 120
3 HARDWARE SOLUTIONS
Hardware Article Code
Controller (built-in version) c-pro 3micro CHIL EPU2LXP1CH
Controiller (blind version) c-pro 3micro CHIL EPU2BXP1CH
I/O expansion c-pro 3 EXP micro+ EPU2EXP
EEV driver (built-in version) EVDRIVE03 EPD4DF3
EEV driver (blind version) EVDRIVE03 EPD4BC3
To manage the second circuit it is necessary to use an I/O expansion c-proEXP micro+ and to manage the electronic expansion valve it
is necessary to use a driver EVDRIVE03.
For management of the blind versions it is also necessary to use a remote user interface LCDVgraph, an interfaceequipped with
6keys/edit pages, statesand enablingthe same.
A descriptionof the keysused by the application.
