EVCO S.p.A. c-pro 3 micro CHIL | Application manual ver. 1.0 | Codice 144CP3CHE104
page 38 of 120
PV13 Setpoint HiSH (2) 15.0 10.0 40.0 K CO-V
PV14 Setpoint LOP (2) -40.0 -40.0 40.0 K CO-V
PV15 Setpoint MOP 2) 40.0 -40.0 40.0 K CO-V
PV16 PID –proportional band (2) 7.0 1.0 100.0 K CO-V
PV17 PID –integraltime (2) 120 0 999 sec CO-V
PV18 PID –derivativetime (2) 120 0 999 sec CO-V
PV19 Start-up delay (2) 5 1 255 sec CO-V
PV20 Start-up position (2) 50.00 0.00 100.00 % CO-V
PV21 Stabilization time 0 0 255 sec CO-V
PV22 Stabilization position 100.00 0.00 100.00 % CO-V
PV23
Operation mode:
0= SH algo
1= Manual
0 0 1 CO-V
PV24 Manual position 0.00 0.00 100.00 % CO-V
PV25
SetSH parameters:
0= set1
1= set2
0 0 1 CO-V
PV26
Relay function:
0= Disabled
1=Enabled: any alarm
2=Enabled: probe error
3= LoSH alarm
4= MOP alarm
5= valve alarm
6= solenoid valve
7= solenoid valve + alarms
8= resyncro
6 0 8 CO-V
PV27
Probe type 3:
0= NTC
1= PT1000
0 0 1 CO-V
PV28
Probe type 4:
0= 4..20mA (0.5 – 8)
1= 4..20mA (0 – 30)
2= 0-5V (0 – 7)
3= 0-5V (0 – 25)
4= 0-5V (0 – 60)
5= scaling
0 0 1 CO-V
PV29
Probe type 1:
1= PTC
2= NTC
3= 0..20mA
4= 4..20mA
5= 0-5V
6= 0-10V
7= PT1000
8= NTC K2
9= NTC K3
5 1 9 CO-V
PV30
Probe type 2:
1= PTC
2= NTC
3= 0..20mA
4= 4..20mA
5= 0-5V
6= 0-10V
2 1 9 CO-V
