EVCO S.p.A. c-pro 3 micro CHIL | Application manual ver. 1.0 | Codice 144CP3CHE104
page 20 of 120
6.9 Constructor Menu
The Configuration menu is a Level 4 menu, i.e. it requires entering of the Configuration level password, in order to be able to
display/modify the parameters contained in this branch. Furthermore, this level is only accessible with the machine in OFF mode.
Display LCD Display LED
CONFIGURATION COnF
HARDWARE
H-AI
H-dI
H-AO
H-dO
EVCM C1-C2
vCM1
vCM2
PASSWORD PSd
This menu contains all the machine’s configuration parameters, which determine its operation mode and which functionalities are to be
enabled or disabled.
The CONFIGURATION menu contains the parameters machine configuration.
The HARDWARE menu allows to configure the I/O of the unit.
The EVCM menu allows to configure the main parameters of EVDRIVE03 for each Circuit.
6.10 RTC Menu
This menu contains the functionality of the systems Real Time Clock, as setting the real time clock and setting daily scheduler (PTxx
parameters).
6.11 Alarms Menu
This menu allows viewing and acknowledging of alarms.
Display LCD Display LED
Show Alarms ALrm
Show History HiSt
The SHOW ALARMS menu shows the active alarms. Each time the DOWN key is pressed, the next active alarm is shown. If no alarms
are present, the message “NO ALARMS” is displayed.
The alarm can be acknowledged by pressing the ENTER key for 2 seconds, when the alarm condition is not active anymore.
The ALARM HISTORY page will show the latest alarm. To view the preceding alarm press ENTER key. This can be repeated until the first
alarm is displayed. The history is viewed in a circular manner.
By pressing the ESC key or after 60 seconds of no key activity, the main page will be displayed.
