EVCO S.p.A. c-pro 3 micro CHIL | Application manual ver. 1.0 | Codice 144CP3CHE104
page 91 of 120
9.5.1 Table of connection c-pro 3 micro CHIL
PGUT=11 (2 Circuit)
Controller Analog Inputs
A/I 1 Heat sink exchanger input temperature
A/I 2 Heat sink exchanger output temperature
A/I 3 Heat source exchanger output temperature
Expansion Analog Inputs
A/I Not used
Analog InputsEVDRIVE03 circuit 1
A/I 1 Condensing pressure C1 (4-20mA)
A/I 2 Compressor discharge temperature C1
A/I 3 Compressor intake temperature C1
A/I 4 Evaporation pressure C1 (4-20mA)
Controller Digital Inputs
D/I 1 On/Off
D/I 2 Heat sink exchanger flow meter
D/I 3 Heat sink heat pump 1
D/I 4 Thermal compressor 2
D/I 5 Heat source heat pump 1
D/I 6 Summer/Winter
D/I 7 Heat source exchanger flow meter
Expansion Digital Inputs
D/I 1 Thermal compressor 5
Digital Inputs EVDRIVE03 circuit 1
D/I 1 High pressure C1
D/I 2 Low pressure C1
D/I 3 Thermal compressor 1
Controller Analog Outputs
A/O 1 Water valve C1 (0-10V)
A/O 2 Water valve C2 (0-10V)
Expansion Analog Outputs
A/O Not used
Controller Digital Outputs
D/O 1 Heat sink pump 1
D/O 2 Compressor 1
D/O 3 Compressor 2
D/O 4 Heat sink anti-frost resistance C1
D/O 5 Source pump
D/O 6 Reversing valve C1
D/O 7 Heat source anti-frost resistance C1
Expansion Digital Outputs
D/O 1 Compressor 4
D/O 2 Compressor 5
D/O 3 Reversing valve C2
Digital Outputs EVDRIVE03 circuit 1
D/O VCM 1 Solenoid valve C1
