7.5
DO Configuration (HD01-HD18 parameters)
Below is a table of values for configuring the positions of the digital outputs of the controller and of the expansion.
Parameters
HD01-HD18
Digital Outputs
0
Disabled
1-2
Heat sink pump 1 NC-NO
3-4
Heat sink pump 2 NC-NO
5-6
Heat sourcepump 1 NC-NO
7-8
Heat source pump 2 NC-NO
9-10
Free Coolingexternal fan NC-NO (On/Off orEnabling)
11-12
Compressor 1 NC-NO
13-14
Compressor 2 NC-NO
15-16
Compressor 3 NC-NO
17-18
Circuit 1 reversing valve NC-NO
19-20
Circuit 1 fan step (enabling) NC-NO
21-22
Circuit 1 solenoid valve NC-NO
23-24
Circuit 1 coilsplitter valve (Free Cooling) NC-NO
25-26
Circuit 1 heat sink exchangeranti-frost resistanceNC-NO
27-28
Circuit 1 heat source exchangeranti-frost resistance NC-NO
29-30
Compressor 4 NC-NO
31-32
Compressor 5 NC-NO
33-34
Compressor 6 NC-NO
35-36
Circuit 2 reversing valve NC-NO
37-38
Circuit 2 fan step (enabling)NC-NO
39-40
Circuit 2 solenoid valve NC-NO
41-42
Circuit 2 coil splitter valve (Free Cooling) NC-NO
43-44
Circuit 2 heat sink exchangeranti-frost resistance NC-NO
45-46
Circuit 2heat source exchangeranti-frost resistance NC-NO
47-48
On/Off Free Cooling valve NC-NO
