EVCO S.p.A. c-pro 3 micro CHIL | Application manual ver. 1.0 | Codice 144CP3CHE104
page 84 of 120
B/- Terminal 0 of the transceiver
Analog inputs 7… 9, digital inputs 6… 9 and analog outputs 4… 6.
TERMINAL MEANING
GND Commonanalog inputs and analog outputs
AI7 Analog input 7
AI8 Analog input 8
AI9 Analog input 9
AO4 Analog output 4
AO5 Analog output 5
AO6 Analog output 6
DI6 Digital input 6
DI7 Digital input 7
DI8 Digital input 8
DI9 Digital input 9
COM Common digital inputs
Power supply RS-485 port with Modbus
TERMINAL MEANING
V= Power supply controller
A/+ Terminal 1 of the transceiver RS-485 port
B/- Terminal 0 of the transceiver RS-485 port
CAN + Signal + CAN port
CAN - Signal - CAN port
USB
TERMINAL MEANING
USB USB OTG port
Analog inputs 1… 6, digital inputs 1… 5 and analog outputs 1… 3.
TERMINAL MEANING
AI1 Analog input 1
AI2 Analog input 2
AI3 Analog input 3
AI4 Analog input 4
AI5 Analog input 5
AI6 Analog input 6
DI4 Digital input 4
DI5 Digital input 5
COM Common digital inputs
+12V Power supply transducers
5VS Power supply radiometric transducers
GND Common analog inputs and analog outputs
AO1 Analog output 1
AO2 Analog output 2
AO3 Analog output 3
DI1 Digital input 1
DI2 Digital input 2
DI3 Digital input 3
