EVCO S.p.A. c-pro 3 micro CHIL | Application manual ver. 1.0 | Codice 144CP3CHE104
page 41 of 120
7.2 AI Configuration (HA01-HA18 parameters)
Below is a table of values for configuring the positions of the analog inputs of the controller and of the expansion. The analog inputs can
be configured as digital inputs as well.
Parameters
Analog Inputs
HA01-HA03; HA07-HA09
HA11-HA13; HA17-HA19 HA04-HA06
HA14-HA16
0 0 Disabled
1 1 External ambient temperature
2 2 System entering temperature (Free Cooling)
3 3 Heat sink entering temperature
4 4 Circuit 1 heat sink exchanger entering temperature
5 5 Circuit 2 heat sink exchanger leaving temperature
6 6 Circuit 1 heat source exchanger leaving temperature
7 7 Circuit 2 heat source exchanger leaving temperature
8 8 Circuit 1 coil temperature
9 9 Circuit 2 coil temperature
10 10 Circuit 1 compressor discharge temperature
11 11 Circuit 2 compressor discharge temperature
12 12 Remote temperature (Accumulation tank)
13 - Circuit 1 condensing pressure (4-20mA)
14 - Circuit 1 condensing pressure (0-5V)
15 - Circuit 2 condensing pressure (4-20mA)
16 - Circuit 2 condensing pressure (0-5V)
17 - Circuit 1 evaporation pressure (4-20mA)
18 - Circuit 1 evaporation pressure (0-5V)
19 - Circuit 2 evaporation pressure (4-20mA)
20 - Circuit 2 evaporation pressure (0-5V)
21 - Circuit 1 single pressure (4-20mA)
22 - Circuit 1 single pressure (0-5V)
23 - Circuit 2 single pressure (4-20mA)
24 - Circuit 2 single pressure (0-5V)
25-26 13-14 Summer/Winter NC-NO
27-28 15-16 On/Off NC-NO
29-30 17-18 Set point NC-NO change
31-32 19-20 Heat sinkexchanger flow meter NC-NO
33-34 21-22 Heat source exchanger flow meter NC-NO
35-36 23-24 Heat sink exchanger NC-NOheat pump 1
37-38 25-26 Heat sink exchanger NC-NO heat pump 2
39-40 27-28 Heat source exchanger NC-NO heat pump 1
41-42 29-30 Heat source exchanger NC-NO heat pump 2
43-44 31-32 Free Cooling externalheater fan NC-NO
45-46 33-34 High pressureCircuit 1 NC-NO
47-48 35-36 Low pressureCircuit 1 NC-NO
49-50 37-38 Thermal compressor 1 NC-NO
51-52 39-40 Thermal compressor 2 NC-NO
53-54 41-42 Thermal compressor 3 NC-NO
55-56 43-44 Circuit 1 NC-NO heater fan
57-58 45-46 High pressureCircuit 2 NC-NO
59-60 47-48 Low pressureCircuit 2 NC-NO
61-62 49-50 Thermal compressor 4 NC-NO
63-64 51-52 Thermal compressor 5 NC-NO
65-66 53-54 Thermal compressor 6 NC-NO
67-68 55-56 Circuit 2 NC-NO heater fan
