KEYENCE BL-600 Series User Manual
Page 90
Chapter 5 Installation
80
5
5. Fasten the BL-600 Series.
Fasten the BL-600 Series in the mounting position with M3 screws.
*
The M3 screws are not included. Select the M3 screws after checking the
panel thickness and other factors of the mounting position. (The mounting
hole for the BL-600 Series is 4 mm deep.)
BL-600/601/600HA/601HA
BL-650HA/651HA
Mounting screw (M3)
Mounting hole
Mounting screw (M3)
Mounting hole
