123
Chapter 7 Serial Communication
7
Function Command being Response Description Error
sent code
Change WP12n OK n=0: Single label 00, 02,
Confirm RP12 12n 1: Multi label 1 05, 07,
2: Multi label 2 14
3: Multi label 3
Change WP13n OK N=0: Sends data after 00, 02,
Confirm RP13 13n reading 05, 07,
1: Sends after timing 14
input turns off
Change WP41nnn OK nnn=001 to 225 00, 02,
Confirm RP41 41nnn (by 100 ms step) 05, 09,
14
Change WP43nnn OK nnn=001 to 225
Confirm RP43 43nnn
Change WP10n OK n=0: No addition 00, 02,
Confirm RP10 10n 1: Add 05, 07,
14
Change WP11n OK n=0: No addition
Confirm RP11 11n 1: Add
Change WP14n OK n=0: No addition
Confirm RP14 14n 1: Add
Change WP17n OK n=0: No addition
Confirm RP17 17n 1: Add
Change WP80n OK n=0: No addition
Confirm RP80 80n 1: Add
Change WP86n OK n=0: No addition
Confirm RP86 86n 1: Add
Change WP48nnn OK nnn= 000 to 100 00, 02,
Confirm RP48 48nnn 05, 07,
Change WP49nnn OK nnn= 000 to 100 14
Confirm RP49 49nnn
Change WP55hhh... OK hhh ... = Reading error 00, 02,
Confirm RP55 55hhh... code (within 8 characters) 05, 06,
10, 12,
14
■ Setting Reading Mode/Data Addition Functions
Setting reading
mode
Setting data send
timing
Setting repeat-read
time in multi label
reading mode 1 or 2
Setting decoding
match count
Setting decoding
match count in
additional
information
Setting scans in
additional
information
Note: Effective only
when No. of
decodings are added.
Setting label
orientation in
additional information
Setting code type in
additional information
Setting reading
error code
* Specify the charac-
ters in HEX (hexadeci-
mal) code.
* If the reading error
code is not specified,
hhh... = FF.
Adding a symbol
identifier
Adding PMI (Pre-
ventive mainte-
nance information)
PMI Preset value
1 (L1)
PMI Preset value 2
(L2)
