Chapter 4 Setup Software
42
4
4.2 Setup Procedure
This section describes each of the setting options.
4.2.1 Model selection
Select the model of the bar code reader on the [[Files]] screen.
1. Click “BL-600” for “Model”.
2. Check to see if “BL-600” appears as the title of the dialog box.
4.2.2 [[Main]] (Operation setting) screen
1. Set the following items.
“Read Mode” ➮ See pages 88 to 92.
Select a “Read Mode”.
Details of “Read Mode”
• If “Single” is selected:
The following box appears. Select the “Data-send” option.
➮ See page 88.
• If “Multi 1” or “Multi 2” is selected:
The following box appears. Specify a “Repeat-reading time”
➮ See page 89.
within the range of 1 to 255 (100 ms to 25.5 s).
• If “Multi 3” is selected:
Nothing appears.
Model selection
“BL-600”
“Decoding match count” “Read Mode”
Details of
“Read Mode”
“Additional
information”
“Read error”
[Trigger setup] button
➮ See page 44.
