173
Appendices
Appendices
Appendix L Default Setting List
■ Bar code setup
Parameter Code 1 Code 2 Code 3 Code 4
Code type CODE39 Coda bar UPC/EAN CODE128
Maximum number of digits 32 32 – 32
Minimum number of digits 03 03 – 01
Send start/stop character Don’t send Send – –
Start/stop character type – Lowercase – –
Test check digit Don’t test Don’t test – –
Read JAN (More than All EAN 13-digit,
one can be selected.) – – EAN 8-digit –
and UPC-E
are readable.
Number of output – – 13 digits –
digits of UPC-A
Add “0” to UPC-E – – Don’t add Don’t add
system code
Set specified-digit Don’t set Don’t set Don’t set Don’t set
output function
Set label reading in Don’t set Don’t set Don’t set Don’t set
the specified direction
■ Main setup
Read mode Single
Data send trigger After reading
Decode match count 2
Data addition function None
Reading error code ERROR
■ Trigger input setup
Selection method Level signal trigger
Input time 2 ms
Input polarity Normal Open
Trigger input operation at power-on Disable
Start test mode at trigger input ON Don’t start
Start test mode at power ON Don’t start
Trigger ON command LON
Trigger OFF command LOFF
