Chapter 5
Installation
This chapter describes the procedure and cautions for the installation of the BL-600
Series and special power supply unit.
5.1 Installation of the BL-600 Series ........................................ 72
5.1.1 Situations to check for before installing the BL-600 Series ... 72
5.1.2 Mounting angle and distance ................................................. 74
5.1.3 Mounting the BL-600/601/600HA/601HA .............................. 75
5.1.4 Mounting the BL-650HA/651HA ............................................ 77
5.1.5 Mounting the BL-600 Series without the mounting bracket ... 79
5.2 Installation of the Special Power Supply Unit ................... 81
5.2.1 In-panel installation ................................................................ 81
5.2.2 Installing the BL-U1 ............................................................... 81
5.2.3 Installing the BL-U2 and N-42 ................................................ 83
