69
Chapter 4 Setup Software
4
[Code 1 setup Bar code = CODE39
[Max code length] [32]
[Min code length] [3]
[Send start/stop character (*)] [_] Enable
[Inspect check-digit [Modulus 43] [_] Enable
[Send check-digit] [x] Enable
-----Options setup------
[Max code length output]
[x] Not used [_] Forward [_] Reverse
[Effective] [32]
[Starting] [1]
[Specify label orientation] [x] Not used [_] Forward [_] Reverse
[Code 2 setup] Bar code = Codabar
[Max code length] [32]
[Min code length] [3]
[Start/stop character] [_] Do not send [x] Lower-case [_] Upper-case
[Inspect check-digit] [_] Enable
[Send check-digit] [x] Enable
[Type of check-digit] Modulus 16
-----Options setup------
[Max code length output]
[x] Not used [_] Forward [_] Reverse
[Effective] [32]
[Starting] [1]
[Specify label orientation] [x] Not used [_] Forward [_] Reverse
[Code 3 setup] Bar code = UPC/EAN
[Read EAN 13(UPC-A)] [x] Enable
[Read EAN 8] [x] Enable
[Read UPC-E] [x] Enable
[No. of UPC-A output] [x] 13 digits [_] 12 digits
[Add UPC-E system code 0] [x] Do not add [_] Add
-----Options setup-----
[Max code length output]
[x] Not used [_] Forward [_] Reverse
[Effective] [32]
[Starting] [1]
[Specify label orientation] [x] Not used [_] Forward [_] Reverse
[Code 4 setup] Bar code = CODE128
[Max code length] [32]
[Min code length] [1]
[EAN-128 support] [_] Enable
-----Options setup-----
[Max code length output]
[x] Not used [_] Forward [_] Reverse
[Effective] [32]
[Starting] [1]
[Specify label orientation] [x] Not used [_] Forward [_] Reverse
Printed: 99/08/07 20:40:28
(2/2)
