Chapter 7 Serial Communication
118
7
7.3.2 Details on parameter setting commands
The following describes how to change the BL-600’s settings through command
communication.
You can use the setup software to change the BL-600’s settings instead of these
commands.
Communication details
1. Send the direct control command SSET to the BL-600.
The BL-600 will shift to setting mode.
After successfully executing the command, the BL-600 sends back an OK.
2. The BL-600 Series shifts to the setting mode.
If the command is successfully executed: The BL-600 Series sends back an
“OK.”
3. Send the command for an item to be changed (setting change command).
If the command is successfully executed: The BL-600 Series sends back an
“OK.”
If an error occurs: The BL-600 Series sends back an “ERR** (**: Error code).”
4. To confirm the current settings, send a setting confirmation command.
If the command is successfully executed: The BL-600 Series sends back the
setting data.
If an error occurs: The BL-600 Series sends back an “ERR** (**: Error code).”
5. To save the settings in the EEP-ROM, send “SAVE” to the BL-600 Series.
Once the settings have been saved in the EEP-ROM, the BL-600 Series will
start with the new settings the next time it is turned on.
If the command is successfully executed: The BL-600 Series sends back an
“OK.”
If an error occurs: The BL-600 Series sends back an “ERR** (**: Error code).”
6. To quit the setting mode and perform normal bar code reading, send “SEND” to
the BL-600 Series.
If the command is successfully executed: The BL-600 Series sends back an
“OK.”
If an incorrect command is sent: The BL-600 Series sends back an “ERR** (**:
Error code).”
Communication format
When the command format is [Command][CR], the response format is
[Response][CR]. When the command format is [STX][Command][ETX], the
response format is [STX][Response][ETX].
* can be added at the end of the command being sent. In this case, how-
ever, is not added to the response data.
Note 1: When is added before the command being sent, characters in the
BL-600’s command receiving buffer are cleared.
Note 2: If the BL-600’s command receiving buffer contains erroneous characters
due to a data transmission error during communication, add to the com-
mand being sent.
Note 3: For command communication, set the time duration between transmission
of each character (byte) to up to 30 seconds. If this duration exceeds 30 seconds,
the BL-600 cancels the received characters.
Command Response
Command CR Response CR
STX Command ETX STX Response ETX
