Chapter 4 Setup Software
38
4
4.1 Installing and Operating the Setup Software
This section describes the installation and operation procedures of the setup
software.
4.1.1 Installation and operation procedures
The following chart shows the installation and setup procedures of the setup
software.
*
The shaded boxes indicate an operation of the setup software or a personal
computer.
Check the operating environment. ➮ See page 39.
Install the setup software. ➮ See page 39.
Connect the BL-600 Series to a personal ➮ For the applicable cable
computer with the RS-232C cable. and wiring, see “3.1
Connecting BL-U1
and Wiring” on page 16
or “3.2 Connecting the
BL-U2 or N-42 and
Wiring” on page 25.
Start the setup software. ➮ See pages 39 to 40.
Select “BL-600” for “Model”. ➮ See page 42.
Specify each item. ➮ See pages 42 to 54.
Press the TEST switch of the BL-600 ➮ See page 54.
Series for 8 seconds.
Send the updated settings to ➮ See page 54.
the BL-600 Series. * The current settings of
the BL-600 Series can
be read from the PC.
* If the multi-drop link is
established with the
N-400, the settings of
the BL-600 Series can
also be changed via
the N-400.
➮ See pages 57 and 58.
Press the TEST switch of the BL-600 ➮ See page 56.
Series once.
Save or print the settings as required. ➮ See pages 60 and 61.
Quit the setup software. ➮ See page 40.
➞
➞
➞
➞
➞
➞➞
➞
➞➞
